148 Appendix B: Technical information
27 P1_LVDS/TTL_AUX_OUT1- Auxiliary output 1 for acq. path 1 (negative).
See pin 11 for more information.
28 LVDS/TTL_AUX_IN1- Auxiliary input 1 for an unspecified acq. path (negative).
See pin 12 for more information.
29 P0_LVDS/TTL_AUX_OUT1- Auxiliary output 1 for acq. path 0 (negative).
See pin 44 for more information.
30 P0_LVDS/TTL_AUX_OUT0- Auxiliary output 0 for acq. path 0 (negative).
See pin 15 for more information.
31 LVDS/TTL_AUX_IN6- Auxiliary input 6 for an unspecified acq. path (negative).
See pin 32 for more information.
32 LVDS/TTL_AUX_IN6+ Auxiliary input 6 for an unspecified acq. path (positive).
Signals only supported for acq. path 0, 1, and 2: user-defined input 8.
Signals only supported for acq. path 3: user-defined input 2, or field, data valid, CSYNC, or HSYNC
input.
Signals supported for any acq. path: trigger input 2.
33 P3_LVDS/TTL_AUX_OUT0+ Auxiliary output 0 for acq. path 3 (positive).
Supported signals: user-defined output 0, exposure output 0, or HSYNC output.
34 LVDS/TTL_AUX_IN0- Auxiliary input 0 for an unspecified acq. path (negative).
See pin 35 for more information.
35 LVDS/TTL_AUX_IN0+ Auxiliary input 0 for an unspecified acq. path (positive).
Signals only supported for acq. path 0: user-defined input 2, or field, data valid, CSYNC, or HSYNC
input.
Signals only supported for acq. path 1, 2, and 3: user-defined input 4.
Signals supported for any acq. path: trigger input 2.
36 GND Ground.
37 GND Ground.
38 LVDS/TTL_AUX_IN3- Auxiliary input 3 for an unspecified acq. path (negative).
See pin 39 for more information.
39 LVDS/TTL_AUX_IN3+ Auxiliary input 3 for an unspecified acq. path (positive).
Signals only supported for acq. path 0: user-defined input 5.
Signals only supported for acq. path 1: user-defined input 3, or timer clock or VSYNC input.
Signals only supported for acq. path 2 and 3: user-defined input 7.
Signals supported for any acq. path: trigger input 3.
40 P2_LVDS/TTL_AUX_OUT0+ Auxiliary output 0 for acq. path 2 (positive).
Supported signals: user-defined output 0, exposure output 0, or HSYNC output.
Pin
Signal
1
Description
