Connectors on Matrox Solios eA/XA 147
8 LVDS/TTL_AUX_IN2+ Auxiliary input 2 for an unspecified acq. path (positive).
Signals only supported for acq. path 0: user-defined input 4.
Signals only supported for acq. path 1: user-defined input 2, or field, data valid, CSYNC, or HSYNC
input.
Signals only supported for acq. path 2 and 3: user-defined input 6.
Signals supported for any acq. path: trigger input 2.
9 GND Ground.
10 GND Ground.
11 P1_LVDS/TTL_AUX_OUT1+ Auxiliary output 1 for acq. path 1 (positive).
Supported signals: user-defined output 1, exposure output 1, or VSYNC output.
12 LVDS/TTL_AUX_IN1+ Auxiliary input 1 for an unspecified acq. path (positive).
Signals only supported for acq. path 0: user-defined input 3, or timer clock or VSYNC input.
Signals only supported for acq. path 1, 2, and 3: user-defined input 5.
Signals supported for any acq. path: trigger input 3.
13 GND Ground.
14 GND Ground.
15 P0_LVDS/TTL_AUX_OUT0+ Auxiliary output 0 for acq. path 0 (positive).
Supported signals: user-defined output 0, exposure output 0, or HSYNC output.
16 LVDS/TTL_AUX_IN7- Auxiliary input 7 for an unspecified acq. path (negative).
See pin 1 for more information.
17 P3_LVDS/TTL_AUX_OUT1- Auxiliary output 1 for acq. path 3 (negative).
See pin 2 for more information.
18 P3_LVDS/TTL_AUX_OUT0- Auxiliary output 0 for acq. path 3 (negative).
See pin 33 for more information.
19 GND Ground.
20 P2_LVDS/TTL_AUX_OUT1+ Auxiliary output 1 for acq. path 2 (positive).
Supported signals: user-defined output 1, exposure output 1, or VSYNC output.
21 GND Ground.
22 LVDS/TTL_AUX_IN4- Auxiliary input 4 for an unspecified acq. path (negative).
See pin 7 for more information.
23 GND Ground.
24 LVDS/TTL_AUX_IN2- Auxiliary input 2 for an unspecified acq. path (negative).
See pin 8 for more information.
25 P2_LVDS/TTL_AUX_OUT0- Auxiliary output 0 for acq. path 2 (negative).
See pin 40 for more information.
26 GND Ground.
Pin
Signal
1
Description
