Matrox Solios Series - Page 149

Connectors on Matrox Solios eA/XA 149
To build your own cable, you can purchase the following parts:
These parts can be purchased from third parties such as Digi-Key Corporation
(www.digikey.com).
41 GND Ground.
42 P1_LVDS/TTL_AUX_OUT0- Auxiliary output 0 for acq. path 1 (negative).
See pin 43 for more information.
43 P1_LVDS/TTL_AUX_OUT0+ Auxiliary output 0 for acq. path 1 (positive).
Supported signals: user-defined output 0, exposure output 0, or HSYNC output.
44 P0_LVDS/TTL_AUX_OUT1+ Auxiliary output 1 for acq. path 0 (positive).
Supported signals: user-defined output 1, exposure output 1, or VSYNC output.
1. Note that only signals defined for acquisition path 0 (those that begin with P0), the common auxiliary input signals ( LVDS/TTL_AUX_), and the grounds (GND) apply
to the Matrox Solios eA/XA Single board. Only signals defined for acquisition paths 0 and 1 (P0 or P1), the common auxiliary input signals (LLVDS/TTL_AUX_), and
the grounds (GND) apply to the Matrox Solios eA/XA Dual board.
Pin
Signal
1
Description
Manufacturer: NorComp, Inc.
Connector: 180-044-102-001
Backshell: 970-025-010-011
