Matrox Solios Series - Page 153

Connectors on Matrox Solios eA/XA 153
A13 P1_LVTTL_AUX_OUT0 Auxiliary output 0 for acq. path 1. B13 P1_LVTTL_AUX_OUT1 Auxiliary output 1 for acq. path 1.
A14 P2_LVTTL_AUX_OUT0 Auxiliary output 0 for acq. path 2. B14 P2_LVTTL_AUX_OUT1 Auxiliary output 1 for acq. path 2.
A15 P3_LVTTL_AUX_OUT0 Auxiliary output 0 for acq. path 3. B15 P3_LVTTL_AUX_OUT1 Auxiliary output 1 for acq. path 3.
A16 P0_CTRL_AUX_OUT LVDS/TTL selector for acq.
path 0.
B16 P1_CTRL_AUX_OUT LVDS/TTL selector for acq.
path 1.
A17 P2_CTRL_AUX_OUT LVDS/TTL selector for acq.
path 2.
B17 P3_CTRL_AUX_OUT LVDS/TTL selector for acq.
path 3.
A18 3.3 V 3.3 V power. B18 3.3 V 3.3 V power.
A19 GND Ground. B19 GND Ground.
A20 LVTTL_AUX_IN0 Auxiliary input 0 for an
unspecified acq. path.
B20 LVTTL_AUX_IN1 Auxiliary input 1 for an
unspecified acq. path.
A21 LVTTL_AUX_IN2 Auxiliary input 2 for an
unspecified acq. path.
B21 LVTTL_AUX_IN3 Auxiliary input 3 for an
unspecified acq. path.
A22 LVTTL_AUX_IN4 Auxiliary input 4 for an
unspecified acq. path.
B22 LVTTL_AUX_IN5 Auxiliary input 5 for an
unspecified acq. path.
A23 LVTTL_AUX_IN6 Auxiliary input 6 for an
unspecified acq. path.
B23 LVTTL_AUX_IN7 Auxiliary input 7 for an
unspecified acq. path.
A24 CTRL_AUX_IN0-1 LVDS/TTL selector. for auxiliary
input 0 and 1.
B24 CTRL_AUX_IN2-3 LVDS/TTL selector for auxiliary
input 2 and 3.
A25 CTRL_AUX_IN4-5 LVDS/TTL selector for auxiliary
input 4 and 5.
B25 CTRL_AUX_IN6-7 LVDS/TTL selector for auxiliary
input 6 and 7.
1. Note that only signals defined for acquisition path 0 (those that begin with P0), the common auxiliary input signals (LVTTL_AUX_), and the grounds (GND) and power
supply pins apply to the Matrox Solios eA/XA Single board. Only signals defined for acquisition paths 0 and 1 (P0 or P1), the common auxiliary input signals
(LLVDS/TTL_AUX_), and the grounds (GND) and power supply pins apply to the Matrox Solios eA/XA Dual board.
Pin
Signal
1
Description Pin
Signal
1
Description
