Page 95 of 188
User Manual MAS-100 Regulus en.docx, Version: 4.0
18) Once the process is done, the final calibration re-
sult will be displayed by the value Deviation from
the Target Air Flow.
A calibration was successful if:
Deviation from the Target Air Flow is within ± the
Maximum allowed deviation.
Successful calibration, value
marked green:
Failed calibration, value marked
red:
Note
The calibration also fails if at least one of the values in the row of Devia-
tion from target air flow is out of the allowable range.
19) Press Calibration certificate.
20) Enter the Certificate Nr.,
then Press OK.
21) The test protocol is exported automatically to a PDF file in a separate window.
The PDF file can be printed and signed if required.
22) If used, remove the MAS-100 Family Calibration Disk or the Petri dish.
23) End of process.
