MAGNUM KEYPAD/DISPLAY REVISION 2.2
25
7.1. GRAPHS (Relay or Sensor)
7.2. GRAPHS (Edit)
Pressing the Menu Key
• Results in displaying the 10 available Menu
items. The highlight is on the Status display.
• To select any item use the ▲ ▼ ◄ ► arrow
keys to position the highlight and press
↲.
• To understand the options select F1 for help.
• To display the current Graphs Screens press the
Enter Key.
Select Function F1
Graphs Relay or Sensor
• On the top line shows Graph and Sensor being
displayed.
• The next lines layout the graph based on the
scale required.
• At the bottom of the graph the graph time frame
is shown.
• Pressing F1 displays sample time for editing
• Pressing F2 or F3 selects relays or analog
outputs for display.
Select Menu & Press ↲
Select Menu & Press ↲
Graphs (Edit)
• The background shows the graph.
• The pop up window shows the current sample
rate.
• By pressing
↲ you may change the sample time.
• Pressing F2 or F3 pages the current screen up
or down the current selection.
Chapter - 7. Graphs
To Next Page
