MAGNUM KEYPAD/DISPLAY REVISION 2.2
26
8.1. SETPOINTS (Value)
Pressing the Menu Key- Setpoints
• Results in displaying the 10 available Menu
items. The highlight is on the Setpoints display.
• To select any item use the ▲ ▼ ◄ ► arrow
keys to position the highlight and press
↲.
• To understand the options select F1 for help.
• To display the current Setpoints Screens press
the Enter Key.
Select Menu & Press ↲
Setpoints Value
• The top line shows Setpoints & ◄► which allows
you to move screen to left or right.
• The second line shows column headings.
• The third through sixth line shows up to four setpoints
& their current value.
• Pressing F2 or F3 pages the current screen up or
down the current selection
• Setpoints are displayed based on authorization level.
Select Menu & Press ↲
Chapter - 8. Setpoints
