MAGNUM KEYPAD/DISPLAY REVISION 2.2

10.1. LOCKOUT RESET (Reset)

Pressing the Menu Key - Lockout

• Results in displaying the 10 available Menu

items. The highlight is on the Lckout RST display.

• To select any item use the ▲ ▼ ◄ ► arrow

keys to position the highlight and press

↲.

• To understand the options select F1 for help.

• To display the current Lckout RST press the

Enter Key.

Press ↲

Lockout Reset

• The top line shows Main Menu.

• The pop up window displays Lockout Reset Yes

or NO..

• If there are no current lockouts the response will

be No Current Lockouts.

• Using the ▼ or ▲ arrows select your response

then press

↲.

• The system is set for a limited number of resets

per day to avoid damage.

Select Menu Key

Press F1 twice to return to Main menu

Chapter - 10. Lockout Reset
