MCS MCS-DOOR-KEYPAD - MCS-MAGNUM-DOOR; MCS-MAGNUM-OEM

MAGNUM KEYPAD/DISPLAY REVISION 2.2
6
1.2. MCS-MAGNUM-DOOR
1.3. MCS-MAGNUM-OEM
PANEL MOUNT PACKAGE
•Magnum
•Panel Mount Keypad/Display
•For rainproof enclosures
•115/230 eld selectable
•24 vac option
•10 Relay outputs (6.3 amps)
•12 Analog or Digital inputs
•4 Digital inputs
•RS 485
•Ethernet
Graphics Display
• 128 x 64 Dot pixel graphics LCD
• 2.8” Diagonal viewing area
• White characters on Dark background (reversible)
Function Keys
Direction Movement Keys
Enter Key
Menu Key
