Memmert UNplus - Technical Data and Compliance Standards

Construction and Description
14 D53182 02/2024
1
2
3
4
5
6
7
8
9
10
1 Type designation 2 Operating voltage
3 Applicable standard 4 Degree of protection
5 CE conformity 6 Manufacturer's address
7 Information regarding disposal 8 Temperature range
9 Connected loads / power ratings 10 Appliance number
See also
2 Design [}11]
3.7 Technical Data
Appliance size 30 55 75 110 160 260 450 750 1060
Stainless steel
interior
Volume l 32 32 74 108 161 256 449 749 1060
Width A mm 400 400 400 560 560 640 1,040 1,040 1,040
Height B mm 320 320 560 480 720 800 720 1,200 1,200
Depth C mm 250 250 330 400 400 500 600 600 850
Max. number of shelves Pc 3 3 6 5 8 9 8 14 14
Max. loading per shelf kg 20 20 20 20 20 20 30 30 60
Max. loading per appliance kg 60 60 120 175 210 300 300 300 300
Max. loading per insertable/
removable drip tray
kg 1.5 1.5 1.5 3.0 3.0 4.0 8.0 8.0 8.0
Max. loading per bottom
drip tray
kg 1.5 1.5 1.5 3.0 3.0 4.0 8.0 8.0 8.0
Patterned
stainless steel
housing
Width D mm 585 585 585 745 745 824 1,224 1,224 1,224
Height E mm 704 704 944 864 1,104 1,183 1,247 1,720 1,720
Depth F mm 434 434 514 584 584 684 784 784 1,035
Temperature Operating temperature
range
°C at least 5 (UN/UNplus) or 10 (UF/UFplus) above room
temperature up to +300
Setting temperature range °C +20 up to +300
Adjustment precision °C up to 99.9: 0.1 / from 100: 0.5
Further data Power consumption
(50/60Hz)
230V W 1,600 2,000 2,500 2,500 2,800 3,400 -
115V W 1,600 1,700 1,800 1,800 1,800 1,800 -
400V W - 5,800 7,000 7,000
3 x 230V
w/o
neutral
W - 5,800 7,000 7,000
3 x 208V W - 4800 5700 5700
Max. current consumption
(50/60Hz)
230V A 7.0 8.7 10.9 10.9 12.2 14.8 -
115V A 13.9 14.8 15.6 15.6 15.6 15.6 -
