Memmert UNplus - Installation Options and Mounting

Delivery, Transport and Setting Up
20 D53182 02/2024
ü The clearance from the ceiling must not be less than 20cm and the side clearance
from walls or nearby appliances must not be less than 5cm. Sufficient air circulation
in the vicinity of the appliance must be guaranteed at all times.
ü For appliances with castors or for appliances standing on sub frames with castors,
always position the castors in a forward direction and lock the castor brakes to ensure
that the appliances remain securely in place.
▶ Place the unit in the designated position as shown below.
See also
2 Technical Data [}14]
2 Nameplate [}13]
4.6.2 Installation Options
Setting up Comments 30 55 75 110 160 260 450 750 1060
Floor
Table Check the load-bearing
capacity first
Stacked No more than two
appliances; mounting
material (feet) provided
Wall mounting bracket Separately packaged
fastening material is
included in the scope of
delivery. Observe the
assembly instructions
provided.
