Delivery, Transport and Setting Up
21 D53182 02/2024
Setting up Comments 30 55 75 110 160 260 450 750 1060
Sub frame with/without castors
Castor frame
Height-adjustable feet
4.6.3 Anti-tilt bracket
Attach the appliance to a wall with the anti-tilt bracket. The anti-tilt bracket is included in
the scope of delivery.
1. Screw the anti-tilt bracket to the back of the appliance as illustrated.
i
Depending on the ambient conditions, the anti-tilt bracket can be fastened at one of the
two holes provided in the appliance.
2. Bend the anti-tilt bracket up by 90° to achieve the required clearance from the wall
(observe the minimum clearance).
3. Find a suitable wall, drill a hole, insert a plug and screw on the anti-tilt bracket.
4.6.4 Adjusting the Doors
You can adjust the doors if necessary, for example if they are warped due to uneven
flooring. There are two adjusting screws on each door for this purpose; one at the top and
one at the bottom.
First, adjust the setting at the top of the door and, if this is not sufficient, adjust the
bottom.
i
A service video which explains how to adjust the door is available:
www.memmert.com/de/downloads/media/service-videos/
