Mercury 45 Service Manual

CARBURETOR
90-828631R3 MARCH 1999 Page 3B-5
Carburetor Linkage
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 DIAPHRAGM
2 1 JOINT
3 3 SCREW Drive Tight
4 1 PIPE
5 1/2
PIPE (Qty. of 2 with carb with adjustable pilot screw/
Qty. of 1 with carb with non-adjustable pilot screw)
6 1 PIPE
7 1 PIPE
8 1 CHOKE ROD
9 4 JOINT
10 2 WASHER
11 1 CHOKE ROD
12 1 CHOKE ROD
13 2 COLLAR
14 2 JOINT
15 1 CHOKE ROD
16 1 CHOKE ROD
17 2 SCREW Drive Tight
18 1 THROTTLE DAMPER
19 1 SPRING
20 1 CHOKE ROD
21 1 STARTER LEVER
22 1 STARTER LEVER
23 1 WASHER
24 1 SCREW
25 1 WASHER
26 2 SCREW Drive Tight
27 1 AUTO STARTER
28 1 SOLENOID
29 1 COVER
30 1 BRACKET (Included W/825105A1 ON INTAKE)
31 2 SCREW Drive Tight
32 1 NUT
33 1 WASHER
34 1 WIRE PULL
35 1 SPRING
36 1 PLATE
37 1 SCREW Drive Tight

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
