CARBURETOR
Page 3B-22 90-828631R3 MARCH 1999
Solenoid Coil
1. Unhook spring and remove screws.
2. Loosen locknut to free wire pull from coil assembly.
28379
a
b
c
d
a-Spring
b-Screw (2)
c-Lock Nut
d-Wire Pull
Electrothermal Plunger Removal
1. Remove cover (if so equipped).
2. Remove screws.
28379
a
b
a-Cover
b-Screw (2)
