IGNITION
90-828631R3 MARCH 1999 Page 2A-21
FLYWHEEL WITH LOAD RING & SPACER
53278
110
a
c
b
d
e
110
4-Stroke Outboard Oil (92-828000A12)
a-Flywheel Key
b-Washer
c-Nut
d-Spacer
e-Load Ring
NOTE: Load Ring is for one time use and must be replaced if flywheel is removed.
Flywheel Nut Torque
116 lb-ft (157 Nm)
