CYLINDER BLOCK/CRANKCASE
Page 4B-1190-828631R3 MARCH 1999
Removing Powerhead Components
1. Place powerhead on Powerhead Stand.
a
91-827001A1
91-812549
a-Powerhead Stand (91-827001A1-Non-Bigfoot) (91-812549-Bigfoot)
2. Remove flywheel, stator, trigger base, and timing belt. Refer to Section 4 Part A.
30033
1
4
2
3
