IGNITION

90-828631R3 MARCH 1999 Page 2A-5

Flywheel

REF.

TORQUE

REF

NO.

QTY. DESCRIPTION lb-in. lb-ft Nm

1 1 COVER

2 2 GROMMET

3 1 TUBING (19 IN.)

4 2 DAMPER

5 1 NUT 116 157

6 1 WASHER

7 1 FLYWHEEL

8 1 DECAL-Warning Spinning flywheel

9 3 SCREW (M6 x 25) 75 8.5

10 1 STATOR

11 1 BASE–Stator

12 2 SCREW 100 11.5

13 2 PIN

14 1 KEY

15 1 COIL–Pulser

16 2 SCREW (M5 x 10) 45 5.0

17 1 DECAL-Warning Neutral

18 1 DECAL-Engine Oil/Valve clearance

19 1 DECAL-EPA INFO (1999)(SEE NOTE)

NOTE: THE EPA LABEL HAS IMPORTANT INFORMATION ON EPA EMISSION REGULATIONS. REPLACE ANY

MISSING OR UNREADABLE EPA LABEL.
