MANUAL TILT ASSIST
90-828631R3 MARCH 1999 Page 5D-27
Reassembly - O-Ring and Seal Placement
1
2
3
5
4
14
6
7
9
11
12
10
13
8
NOTE: Lubricate all O-rings using Quicksilver Power Trim and Steering Fluid. If not avail-
able, use automotive (ATF) automatic transmission fluid.
NOTE: It is recommended that all O-rings be replaced when servicing tilt system.
