Mercury 45 Service Manual

CYLINDER BLOCK/CRANKCASE
Page 4B-790-828631R3 MARCH 1999
Cylinder Block
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 CYLINDER BLOCK
2 2 DOWEL PIN
3 3 PLUG
4 1 PIPE PLUG (1/4-14)
5 1 PIPE PLUG (3/4-14)
10 BEARING (BROWN)
6 10 BEARING (BLACK)
10 BEARING (BLUE)
7 10 SCREW (M8 x 1.25 x 82) 264 22 30
8 10 SCREW (M6 x 35) 106 12
9 1 GASKET
10 1 OIL FILTER 155 12.9 17.5
11 1 NIPPLE 29.5 40
12 1 GASKET
13 1 EXHAUST COVER
14 1 PIPE PLUG
15 1 THERMOSTAT
16 1 GASKET
17 1 COVER
18 12 SCREW (M6 x 35) 106 12
19 1 TUBING (11 IN.)
20 1 STA STRAP
21 1 ELBOW
22 1 PLUG-Serial Number

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
