Mercury 45 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
Page 5A-18 90-828631R3 MARCH 1999
5. Install remaining co-pilot components.
54275
54276
a
b
c
d
e
f
g
a-Brake Disc (2)
b-Swivel Head Plate
c-Hex Shoulder Screw (2)
d-Brake Plate
e-Nylon Washer
f-Co-Pilot Lever
g-Lock Nut (Tighten Next Step)

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
