Mercury 45 Service Manual

POWER TRIM
90-828631R3 MARCH 1999 Page 5C-5
Power Trim
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
– 1 POWER TRIM PUMP (NON-BIGFOOT) S/N- & UP
– 1
POWER TRIM PUMP (BIGFOOT)
– 1 POWER TRIM PUMP (NON-BIGFOOT) S/N- & BELOW
– 1 POWER TRIM PUMP (BIGFOOT)
1 SHOCK ROD KIT (S/N- & UP)
1 1 SHOCK ROD KIT (NON-BIGFOOT) S/N- & BELOW
1 SHOCK ROD KIT (BIGFOOT)
2 1 MEMORY PISTON ASSEMBLY
3 1 O RING REBUILD KIT
4 2 O RING
5 1 CYLINDER ASSEMBLY
6
1 TRIM LIMIT VALVE KIT (NON-BIGFOOT)
6
1 TRIM LIMIT VALVE KIT (BIGFOOT)
7 1 PUMP ASSEMBLY
8 1 MOTOR KIT
9 1 RESERVOIR PLUG
10 1 MANUAL RELEASE ASSEMBLY
11 1 MANIFOLD KIT
12 1 SCREW KIT (MOTOR)
13 1 DRIVE SHAFT
14 1 FILTER KIT
15 1 P.O. CHECK ASSEMBLY KIT
16 1 CABLE
– 1 O RING KIT (COMPLETE TRIM)
17 2 GROOVE PIN
18 1 ANCHOR PIN
19 1 PIN
– 1 TRIM HARNESS
20 1 HARNESS-Trim
21 2 RELAY
22 2 BRACKET
23 2 GROMMET
24 2 BUSHING
25 2 DECAL-Trim Relay
26 2 SCREW (M6 x 25)
27 2 PLUG
28 1 ADAPTOR HARNESS
A - Torque cylinder cap to 45 lb-ft (61 Nm)
B - Torque screws to 80 lb-in. (9.0 Nm)
C - Torque screws to 70 lb-in. (7.9 Nm)
D - Torque plugs to 120 lb-in. (13.5 Nm)
E - Torque screws to 100 lb-in. (11 Nm)
F - Torque shock piston to 90 lb-ft (122 Nm)

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
