BIGFOOT GEAR HOUSING
90-828631R3 MARCH 1999 Page 6B-3
7. Bearing Preload Tool (91-14311A2)
8. Mandrel (91-15755)*
73815
9. Backlash Indicator Tool (91-19660--1) 2.07:1 Gear Ratio (14/29)
19660-1
10. Mandrel (91-31106)
11. Oil Seal Driver (91-31108)
12. Threaded Rod (91-31229) and Nut (91-24156)*
13. Slide Hammer (91-34569A1)
