Mercury 45 Service Manual

CHARGING AND STARTING SYSTEM
90-828631R3 MARCH 1999 Page 2B-5
Starter Motor (S/N-0G472132 & Below)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 STARTER MOTOR
2 1 RETAINER
3 1 GEAR
4 1 BRACKET–front
5 1 METAL
6 2 O RING
7 1 WASHER KIT
8 1 ARMATURE
9 1 STATOR
10 3 SPRING
11 1 BRUSH HOLDER ASSEMBLY
12 1 BRUSH SET
13 1 WASHER
14 1 BRACKET–rear
15 2 BOLT
16 1 BOLT (M8 x 45) 22.5 31.0
17 2 BOLT (M8 x 30) 22.5 31.0
18 1 BOLT (M8 x 20) 155 13.0 17.5
19 1 LOCKWASHER
20 1 NUT 60 7.0
21 1 J CLAMP
22 1 CABLE

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
