Merging Anubis - Page 105

105
Max Line Input Level
+24 dBu
Input Impedance (Differential)
~ 10kΩ
THD+N Preamp + A/D 1kHz @ 0 dBFS
< - 104 dB (0.0006%)
Interchannel Crosstalk @ 1kHz
< -140 dB
Sensitivity Range for 0 dBFS (Software controlled)
+24 dBu to -42 dBu
INSTRUMENTS / Hi-Z & LINE INPUTS 3-4
Connector Type
¼” TRS Female
Dynamic Range, ref +18 dBu
136 dB (A-weighted, typ.)
Max Input Level
+18 dBu
Input Impedance (Single ended / Differential)
~ 1MΩ / ~ 2MΩ
Gain Range (Software controlled)
0 dB to +66 dB
THD+N Preamp + A/D 1kHz @ 0 dBFS
< - 111 dB (0.0003%)
Interchannel Crosstalk @ 1kHz
< -150 dB
Sensitivity Range for 0 dBFS (software controlled)
+18 dBu to -48 dBu
Common Mode Rejection Rate (20 Hz – 20 kHz)
< -70 dB
MAIN OUTPUTS 1-2
Connector Type
Neutrik XLR Male
Dynamic Range
123 dB (A-weighted, typ.)
Max output Level (Differential / Single ended)
+24 dBu (12.2 Vrms) / +18 dBu (6.1 Vrms)
Frequency response +0/-0.2dB @ fs = 48 kHz
6 Hz – 22 kHz
Frequency response +0/-3dB @ fs = 96 kHz
2 Hz – 46 kHz
Frequency response +0/-3dB @ fs = 192 kHz
2 Hz – 92 kHz
Output Impedance
< 70Ω
THD+N 1 kHz @ 0 dBFS
< - 110 dB (0.0003%)
Output Level Matching
±0.01 dB
Attenuation Range (Software controlled)
- ∞ dB to 0 dB
Gain Step / Precision
0.5 dB / ±0.05 dB
LINE OUTPUTS 3-4
Connector Type
¼” TRS Female
Dynamic Range
123 dBFS (A-weighted, typ.)
Max output Level Differential / Single ended
+24 dBu (12.2 Vrms) / +18 dBu (6.1 Vrms)
Output Impedance
< 70Ω
THD+N 1 kHz @ 0 dBFS
< - 110 dB (0.0003%)
Output Level Matching
±0.01 dB
Attenuation Range (Software controlled)
- ∞ dB to 0 dB
Gain Step / Precision
0.5 dB / ±0.05 dB
