SETTINGS CATEGORIES DESCRIPTION
GENERAL SETTINGS
Sampling Rate
Selector to the different sampling rates, available from a drop down menu.
Anubis Pro: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Anubis Premium: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz (DXD), 384kHz,
DSD64, DSD128, DSD256
Auto
Auto Sampling Rate mode, when enabled, will make Anubis automatically follow the sampling
rate given by a RAVENNA/AES67 source provided by either; ASIO, Virtual Audio Device (VAD),
MassCore or another interface with PTP clock.
Example 1: User using an external player (such as a DAW) can enable the Auto mode so that
Anubis automatically changes its sampling rate according to the project settings.
Example 2: This Auto setting is also useful in a network configuration following the RAVENNA
ASIO/Virtual Audio Device (VAD) settings, where Anubis will adapt its sampling rate
automatically.
Note: Both examples above are valid provided at least one RAVENNA ASIO or Virtual Audio Device
(formerly Core Audio Driver) stream is connected to an Anubis Source.
Latency
Modes available in samples: AES67 (6), AES67 (12), Ultra (16), Extra (32), AES67 (48)* & Low (64)
The selected mode will determine the device latency over a RAVENNA network. When multiple
RAVENNA devices (e.g. Anubis) are connected over a network, they should be configured in order
to adjust themselves to the lowest latency that can be globally achieved.
* Ex-factory default mode
