50
BASS MANAGEMENT
Bass Management is available for Speaker Set Monitor sets with at least one LFE channel type.
Based on the ZMAN Anubis board that offers built-in high-quality filters directly processed into
the FPGA. Those will apply a crossover frequency from all channels (except LFE and LF2) and
route low frequency information to the LFE channel(s).
The Monitor Mission uses these filters to achieve complete bass management for speaker
setups having one or two LFE channels and thus support standards such as 5.1 or 7.1 and go
beyond with support for 10.2 or even 22.2 formats. This ensures long term compatibility for
upcoming immersive standards which use a high channels count.
Bass Management Settings
Monitor
Enable or disable the Bass Management for a Speaker Set which includes at least one LFE
channel type.
Crossover Frequency
Adjustable crossover frequency, from 20 Hz to 200 Hz
Filter slope
Adjustable cut off slope: 6/12/18/24/30/36 dB/octave
Depending on the total number of channels to be processed, some of the highest slopes might
not be available.
Note: a total of 28 bands are available for Bass management, e.g. 24/dB/octave max is possible with a
5.1 setup.
LFE Boost
Optional +10 dB LFE boost
Note: When using a Monitor Set configured with 2 LFE channels, those will be processed Stereo-wise.
