ANUBIS TECHNICAL SPECIFICATIONS
GENERAL
Case Material
Premium machined and anodized aluminium
Dimensions
200 x 128 x 40mm
Weight
950 gr
Top Panel Display
Capacitive Touch, TFT LCD 800 x 480 pixels resolution
16:9 Aspect ratio
Rotary Encoder
Anodized aluminum + Black rubber O-ring
7 x Hardware + Soft buttons
RGB LEDs
Bottom Panel Mic stand thread
3/8" 16BSW European thread incorporated
Note: Americas 5/8" 27UN adaptor not included
POWER
Power Supply Voltage (DC)
9V to 15V DC
Power Supply Connector Type
Barrel jack, int. 2.5mm/out. 5.5mm, with locking function
Power Consumption (Max)
< 15W
PoE (Power Over Ethernet)
IEEE 802.3at PoE+ class 0 Power-over-Ethernet standard
MICROPHONE INPUTS 1-2 (Combo)
Connector Type
Combo Locking Neutrik XLR / TRS
Dynamic Range Mic / Mic Boost
137 dB / 128 dB (A-weighted, typ.)
Max Input level Mic Pad / Mic / Mic Boost
+24 dBu / +12 dBu / +0 dBu
Frequency response +0/-0.2dB @ fs = 48 kHz
9 Hz – 22k Hz
Frequency response +0/-3dB @ fs = 96 kHz
9 Hz – 46 kHz
Frequency response +0/-3dB @ fs = 192 kHz
11 Hz – 94 kHz
THD+N Preamp + A/D 1kHz @ 0 dBFS
< -110 dB (0.0003%)
Interchannel Crosstalk @ 1kHz
< -130 dB
Equivalent Input Noise Mic / Mic Boost (150Ω Source)
< -125 dBu / -128 dBu (A-weighted, typ.)
Common Mode Rejection Rate (20 Hz – 20 kHz)
< -80 dB
Input Impedance (Differential)
~ 10kΩ
Gain Range (Software controlled)
0 dB to +66 dB
Gain Step Coarse / Fine
0.5 dB / 0.1 dB
Phantom Power (Software Switchable Per Channel)
+48V
Phase Reverse (Software Switchable Per Channel)
Yes
Low Cut filter (Software Switchable Per Channel)
-12 dB/octave, 80 Hz
LINE INPUTS 1-2 (Combo)
Connector Type
Combo Locking Neutrik XLR / TRS
Dynamic Range, ref +24 dBu
139 dB (A-weighted, typ.)
