106
HEADPHONES
Headphone Jacks
2 Independent ¼” TRS Female Stereo 6.3 mm
Dynamic Range (A-weighted, typ.) High / Low
< -122 dB / - 117 dB
Max output Level High / Low
17.1 dBu / 7.8 dBu
Frequency response +0/-0.2dB @ fs = 48 kHz
6 Hz – 22 kHz
Frequency response +0/-3dB @ fs = 96 kHz
2 Hz – 46 kHz
Frequency response +0/-3dB @ fs = 192 kHz
2 Hz – 92 kHz
Output Impedance
< 0.035Ω
THD+N 1 kHz @ 0 dBFS High / Low
< -108 dB (0.00039%) / -110 dB (0.0003%)
Gain Range (Software controlled)
- ∞ dB to 0 dB
Gain Step / Precision
0.5 dB / ±0.05 dB
A/D – D/A CONVERSION
Supported Sample Rates PRO
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and
192 kHz
Supported Sample Rates PREMIUM
44.1 kHz up to 352.8 kHz (DXD), 384 kHz, DSD64,
DSD128 & DSD256
Bit Depth Per Sample
32
A/D Latency Sharp Short @ 44.1kHz to 96kHz
5 samples
A/D Latency Sharp Short @ 174.6kHz to 192kHz
6 samples
A/D Latency Sharp Short @ 352.8kHz to 384kHz
7 samples
D/A Latency Sharp / Slow @ 44.1kHz to 384kHz
35 / 9 samples (Apodizing & Brickwall 35 smpl)
COMPLEMENTARY I/O
RAVENNA (Gigabit Ethernet)
Locking EtherCON compatible with standard RJ45 connectors
Built-in Talkback microphone
Mono omnidirectional condenser capsule
GPI/MIDI Input
¼” TRS Female
GPO/MIDI Output
¼” TRS Female
SOFTWARE SPECIFICATIONS
Windows Driver/OS
RAVENNA ASIO v12.0 (ASIO 2.2) for Win7 - 64bit / Win10 - 64bit
Mac Driver/OS
VAD - Core Audio for MacOS 10.8.5 or higher (Intel)
Linux Driver/OS
ALSA Linux RAVENNA/AES67 driver
ANEMAN
Version 1.1.7 and above
