MONITORS
Configure your Monitoring sets, whether you plan to use the Anubis hardware output sets for
your Studio Monitor Speaker, Headphones, Cue Mix or to Remotely control the outputs of an
external compatible device RAVENNA/AES67 (e.g. Horus or Hapi).
Create new Monitor
Create a new Monitor set that can be customized for your needs.
For example configure the Anubis Main (1-2) outputs to control the volume of your DAW Source
through the Anubis Monitoring Engine.
> Enter a Monitor configuration by tapping the Monitor line
Select to delete a Monitor set upon confirmation in message dialog
Enable or disable a Monitor
Disabling a Monitor will hide this one from the Main Anubis menu pages. Doing so will not delete
the Monitor but simply hide it with a gray icon it can be enabled back at any time.
Name
Name the Monitor choosing a predefined name from the drop-down dialog, add numbering or
lettering to the name using the second field.
Mode
Define your Monitor by selecting one of the 3 available Monitor Modes.
1. Speaker Set: Recommended to be used for Speaker Sets (e.g. Stereo Monitors)
2. Headphones: Recommended to be used for Headphones Sets monitoring
3. Cue: Recommended to be used when a specific summation of Sources is need on a
designated Monitor set or when recording to produce a low-latency Cue mix for the performer
foldback.
Important: Speaker Sets and Headphones will monitor the same Sources selection. In order to
