4 Appendix
Titrando Installation Instructions 37
4.1.5 Internal dosing device
Cylinder volume
Exchange unit resolution
Accuracy
1 mL, 5 mL, 10 mL, 20 mL or 50 mL
20'000 steps per cylinder volume
0.025% (typical)
Complies with ISO/DIN Standard 8655-3
4.1.6 Interfaces
USB connections
USB ports 2 USB downstream ports (type A sockets), 500 mA
each, for connection of peripheral devices such as
printer, keyboard, barcode reader or USB-RS232 box
(Metrohm Ordering no. 6.2148.020)
Controller connection
Controller port USB upstream port with additional signals (mini DIN
socket) for the connection of Touch Control or com-
puter to control the Titrando.
Touch Control connection With built-in Touch Control cable
Computer connection With 6.2151.000 cable
MSB connections (MSB = Metrohm Serial Bus)
Dosing device Connection of max. 3 external dosing devices of the
type Dosimat or Dosino to Titrandos with internal dos-
ing drive (MSB 2 to MSB 4) or 4 external dosing de-
vices of the type Dosimat or Dosino to Titrandos with-
out internal dosing drive (MSB 1 to MSB 4).
Stirrer Connection of max. 4 stirrers
Stirrer control: on/off; manual or coordinated with the
titration procedure.
15 steps for speed and direction of rotation selectable.
Remote box Connection of max. 4 remote boxes
Remote boxes are used to select and control external
devices.
4.1.7 Mains connection
Voltage
Frequency
Power consumption
Fuses
100 ... 240 V (± 10%)
50 ... 60 Hz
45 W
electronic overload protection
