Page 54 Electrical installation
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
Mating plug X9, X9A,X9B, X9C
INFORMATION
Mating plug
ARS 2320 FS
ARS 2340 FS and ARS 2360W FS
X9
Phoenix Contact
SPC 5/ 5-ST-7,62 (1996045) or
PC 5/ 5-ST1-7,62 (1777752)
Phoenix Contact
SPC 16/5-ST-10,16 (1711297) or
PC 16/5-ST-10,16 (1967401)
X9A
Phoenix Contact
SPC 5/ 3-ST-7,62 (1996029) or
PC 5/ 3-ST1-7,62 (1777736)
see ARS 2320 FS
X9B
Phoenix Contact
FK-MCP 1,5/ 2-STF-3,81 (1851232) or
MC 1,5/ 2-STF-3,81 (1827703)
see ARS 2320 FS
X9C
Phoenix Contact
SPC 5/ 4-ST-7,62 (1996032) or
PC 5/ 4-ST1-7,62 (1777749)
Phoenix Contact
SPC 16/4-ST-10,16 (1711284) or
PC 16/4-ST-10,16 (1967391)
Recommended cable types:
The cable names given refer to cables made by Lapp. They have proven to be reliable and are
successfully used in many applications. However, it is also possible to use comparable cables from other
manufacturers for example Lütze, Helukabel or SAB Bröckskes.
 LAPP KABEL ÖLFLEX-CLASSIC 110
Cabling and Circuit breaker
Technical data
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Cable cross section 24 VDC Supply (flexible
conductors, wire end sleeve with insulating
collar)
0,5 mm
2
...0,75mm²
Tightening torque for Mating plug with M2
screws
0,22…0,25 Nm
Cable cross section mains (flexible
conductors, wire end sleeve with insulating
collar)
4 mm²
6 mm
2
10 mm
2
Tightening torque for Mating plug with
screws
M3: 0,7…0,8 Nm
M4: 1,7...1,8 Nm
M4: 1,7...1,8 Nm
Recommended Circuit Breaker
B25
B40
B40
