Page 56 Electrical installation
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
INFORMATION
Switching of inductive direct current via relays produces strong currents and sparking.
For interference suppression, we recommend using integrated RC suppressor
elements, for example by Evox RIFA, product name: PMR205AC6470M022 (RC
element with 22  in series with 0.47 µF).
Pin assignment X6 Motor
Pin No.
Denomination
Value
Specification
1
U
0...400 V
eff
Connection of the motor phase U
2
V
0...400 V
eff
Connection of the motor phase V
3
W
0...400 V
eff
Connection of the motor phase W
4
PE
0 V
Connection of motor PE line
Pin assignment X6A Motor temperature sensor
Pin No.
Denomination
Value
Specification
1
PE
0 V
Connection of optional ground conductor PE
2
MT+
-
Motor temperature sensor, normally closed contact,
normally open contact, PTC, NTC, KTY
3
MT-
-
Reference potential
Pin assignment X6B Motor holding brake
Pin No.
Denomination
Value
Specification
1
BR+
24 VDC
Motor temperature sensor, normally closed contact,
normally open contact, PTC, NTC, KTY
2
BR-
0 V
Reference potential
