Page 58 Electrical installation
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
Recommended cable types:
The cable names given refer to cables made by Lapp. They have proven to be reliable and are
successfully used in many applications. However, it is also possible to use comparable cables from other
manufacturers, for example Lütze, Helukabel or SAB Bröckskes / Desina.
 LAPP KABEL Type ÖLFLEX-SERVO 719 CY
 LAPP KABEL Type ÖLFLEX-SERVO-FD 750 P
Cabling
Technical data
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Max. cable length
screened
see chapter 4.3
Cable cross section
(flexible conductors,
wire end sleeve with
insulating collar)
4 mm²
10 mm
2
16 mm
2
Tightening torque for
Mating plug with
screws
M3: 0,7 … 0,8 Nm
M4: 1,7...1,8 Nm
M5: 2,5 Nm
