103
The fuses box is situated under the instrument panel behind the central pillar of the console, take out the protecting grille
and check if the fuses are ok. To facilitate the removal and the fitting, use a needle nosed pliers.
F1A15AStoplight, insrument accessories, radio, cigar lighter
F2A25Ae lectric window winder ✱
F3AFree
F4A5ASpeed captor, Reverse light; fuel pump; de-icing relay;
Anti starter relay; Wiper relay; Load relay
F5A15AIndicator, panel after ignition; Van; Battery loading
F6A25ABack de-icing ✱ ,Front and back wiper Windcscreen wiper
F1B30APre heating and heating relay
F2B20ASide lights, crossing lights, warning, back fog lights
F3B7,5AInside lights, instrument indicator, sound warning
F4B15ARoad lights
F5B20ACentral lock ✱
F6BFree
Always replace the fuses by the same fuses ampering..
Never put someting else at the place of the fuse even if it is temporary.
This could bring a short circuit and a fire could start in the car.
