22
DOOR HINGES
REMOVAL
Take out the door (see page 8).
Take out the front bumper (see page 19).
Take out the front wing (see page 20).
Take out the door hinges, 3 fixing screws per hinge
(set screw when fitting again 7 N/m).
BONNET REMOVAL
Unlock the bonnet without opening and take out the
2 fixing bolts of the hinges from the front pillar.
(set screw when reassembling 3,5 N/m).
Take out the bonnet.
When reassembling the bonnet, adjust this one with the 2 regulating
screws to obtain a correct position with the body.
SEALED BEAM
REMOVAL
Open the bonnet.
Unplug the battery.
Remove the front bumper (see page 19)
Take out the superior fixing nut (see picture)
Unplug the 4 electric connections.
