78
ENGINE CRADLE
EQUIPMENT
Fit the waterproof joint between the manifold and the exhaust tube
Be carefull to the fitting way, (boss up)
Fix the tubulure on the exhaust manifold with 2 M8 screws
without blocking them.
Fix the M12 lower fixing screw of the exhaust tube
on the engine, without blocking it.
Tighten the 2 M8 fixing nuts of the exhaust tube on
the manifold.
Tighten the M12 lower fixing screw of the exhaust tube
on the engine (set screw 45N/m).
