8
To take out the door, open the bonnet and unplug
the battery using the red speed disconnecting cable terminal
(+).
Take off the ducts of the body pillar, take out and unplug
the 2 connectors of the window winder beam and central locking
✱ .
✱ It depends on the version
DOOR REMOVAL
Hold the door with the handle and put the 2 fixing screws
of the hinges.
(Set screw 7 N/m)
The fitting of the door is made at the reverse from the
removal operations.
Before intervening on any components of the
electric setting, unplug the positive cable (red)
of the battery.
