68
CHANGER BRIDGE REMOVAL
Unplug the battery using the red speed (+) disconnecting cable
cable terminal.
Take off the lower soundproof panel.
(see page 58).
Take off the fixing screws of the suspension arms of the
hub.
(set screw when fitting back 40N/m).
With a hub puller (FACOM ref U16B) uncouple the suspension
arms from the hub.
With a screwdriver, act as a lever to disconnect the changer
bridge and take off the transmission.
