1ST VERSION RECEIVER PULLEY FITTING
For the fitting, put the mobile half pulley
on its axle, position the spring on the mobile
pulley in the hole (C) and position the
other spring end in the hole (2) of the fixed
came.
C
2
67
2ND VERSION RECEIVER PULLEY FITTING
For the fitting, put the mobile half pulley
on its axle, position the spring on the mobile
pulley in the hole (A) and position the
other spring end in the hole (4
) of the fixed
came.
A
4
Position the key of the shaft on the same line as the came.
Compress the spring and turn the mobile half pulley
at the reverse from a watch needles , to change a came step.
Fit back the outside circlips.
NOTA : For the usual maintenance of the receiver pulley,
it is not necessary to take it out, a diesel cleaning on the sliding
(behind the spring) is sufficient.
