62
VARIATOR REMOVAL
The complete variator is adjusted in the factory and in case of repairing, it is necessary to use the MICROCAR
original pieces.
It doesn't require a lot of maintenance but to obtain a maximum performance, it is important that the mobile flanges
slide freely. So it can be necessary to clean it well.
POWER PULLEY REMOVAL
NOTA : The first MC1 models can be equiped with the same
variators as the VIRGO.
The adjustments are different, see specific paragraph
(page 64 et 65).
Take out the screw and its fixing washer and take out the pulley
(set screw when reassembling 60N/m)
Take out the nut and its washer bell lock.
(set screw when reassembling 100N/m)
Take out the bell.
