66
RECEIVER PULLEY
DISMANTLING
Take off the fixing nut of the receiver pulley
(set screw when fitting back 60N/m)
Take out the receiver pulley of the axle box and take out the key.
Find the spring position.
Take off the inside circlips compressing the fixed came.
Take out the fixed came and the spring.
Take out the half mobile pulley.
Clean the pieces with diesel and compressed air
Dry well and degrease the pulleys (lubricate with fine oil the
axle of the half fixed pulley).
