Microcar MC1 User Manual

65
• Position 5 adjustment spring spacers (B) thickness 1,2mm (Réf. 0 780 352) in the lower bearing (D)
• fit the spring (Réf. 1 000 660).
• Position 5 other adjustment spacers (B) thickness 1,2mm (Réf. 0 780 352) in the upper bearing (E)
• Position the adjustment spacer (B) thickness 0.6 mm (Réf. 0 780 352) in the upper bearing (E)
• Position the belt setting washers (A) thickness 1mm (Réf. 1 002 568) inside the spring
NOTA : Always share the number of adjustment spacers on each side of the spring.
POWER PULLEY SPRING SETTING
(ADJUSTMENT IN THE FACTORY)
2nd VERSION MODEL
