Microcar MC1 - Power Pulley Spring Setting (1 st Version)

64
• Position the belt setting washers (A)
(Réf. 0 782 373 et 0 782 374) on the shaft of the fixed half pulley.
• Position 4 adjustment spring spacers (B) thickness 1,2mm (Réf. 0 780 352) in the lower bearing (D)
• fit the spring (Réf. 1 000 660).
• Position 2 adjustment spacers (B) thickness 1,2mm (Réf. 0 780 352) in the upper bearing (E)
• Position 1 adjustment spacer (C) thickness 0,6mm (Réf. 0 780 357) in the upper bearing (E)
NOTA : Always share the number of adjustment spacers on each side of the spring.
POWER PULLEY SPRING SETTING
ADJUSTMENT IN THE FACTORY
1ST VERSION MODEL
D
