58
SOUNDPROOF ENGINE
PANEL REMOVAL
Remove the front bumper (see page 19).
Remove the 2 lower flaps of the bumper support
Take off the 2 lower fixing screws of the front soundproof
panel.
Take out the 2 upper fixing screws of the panel.
Take out the fixing screw on the right side.
Undo the soundproof panel taking it to the front.
Take out the 3 fixing screws of the right lower
soundproof panel.
