60
TRANSMISSION
REMOVAL
Place the car on an elevator or on a chassis stand.
Remove the front wheel.
(set screw when fitting again 120N/m)
Take out the suspension arm fixing screw.
(set screw when reassembling 40N/m)
With a hub puller (FACOM ref U16B), uncouple the suspension
arm from the hub.
Take out the transmission end screw on the hub
(set screw when reassembling 120N/m)
Uncouple the hub of the transmission
With a screwdriver, act as a lever to disconnect the
reverser drive axle and take off the transmission.
