71
REVERSER TRANSAXLE
REMOVAL
Before opening the door , we advice you to clean it with petroleum or
diesel and to dry it with compressed air.
Drain the gearbox oil by its oil change hole (27)
Take out the holding screw (31), the spring (29) and the ball (28).
Take out the 8 screws that gather the 2 half housing
Separate the 2 half housing (1) and (2) lightly hiting
with a rubber hammer in the axle of the entry shaft (7).
Never introduce a screwdriver between the 2 half haousing
as lever , not to damage the joints.
Throw the old paper joint (3) between the 2 half housing
and take a new one for the fitting.
Take out the return spring.
Take out reverse gear axle (12).
Take out the entry shaft(7).
