Witty User Manual - EN - v1.5 P. 61 / 171
Example 3: Exercise with 2 “groups” of Gate/Sem: Set the number of repetitions to 2 and the number of
pulses to N after which you want to access the semaphore with the direction change
SEM
1
START
GRP 1
Delay Time
START
GRP 2
?
SEM
2
Delay Time
?
STOP
