LVS-95XX Series Barcode Quality Station Operations Manual
LVS-95XX Series Barcode Quality Station Operations Manual - English Page 22 of 94
Barcodes can be verified in any orientation, which is an integer multiple of 90 degrees.
Barcodes Verified Horizontally
Barcodes Verified Vertically
To Print the Results
To print the verification results, click the Print button on the top, left corner of the Grading Tab screen.
To View the Report
To view the report, right-click on the Print button and an HTML document is generated and displayed on the
screen. The HTML version can be saved as a PDF file by downloading free PDF convertor software from the
Internet to the computer. Refer to the “1. Overall Grade” section, within the “Grading Tab” section of this
manual for detailed instructions.
This concludes the basic operations of the LVS-95XX systems. Each tab at the top of the screen is explained
in detail in the following sections.
