LVS-95XX Series Barcode Quality Station Operations Manual
LVS-95XX Series Barcode Quality Station Operations Manual - English Page 15 of 94
LVS-9510 and Auxiliary Readhead Hardware
Specifications
Physical Properties
Height 10.5” 266.7 mm
Width 11.125” 282 mm
Depth 9.062” 230 mm
Viewing Window 5” x 7” 127 mm x 177.79 mm
Weight
• Unpackaged weight (standalone LVS-
9510 unit) = 6 pounds (2.72 kg)
• Shipping weight (includes all items
packaged in shipping box, such as
power supply, cables, manuals, etc.) =
13 pounds (5.89 kg)
Video Camera
• Monochrome. 5.0 megapixel
Minimum PC Requirements (PC Supplied by User)
• Windows® XP Professional or Windows® 7 (Windows® Vista is not
supported)
• Intel® Core™ 2 Duo Processor (or equivalent)
• 2 GB RAM
• 800 x 600 Resolution
• One available USB 2.0 port (additional ports required for each
Auxiliary Readhead in use)
• The user-supplied computer connecting to the 5.0 MP Auxiliary
Readhead must be running LVS-95XX software version 3.0.8 or
higher.
Top Cover
• 5.5” x 7.5” (139.7 mm x 190.5 mm)
• Weight = 5.5 oz (162.65 grams)
Light Source
• White Light
• Red (660 nm) filter. Optional clear window available for purchase.
Inputs / Outputs
• USB 2.0 port
• Power Supply 12 vdc @ 2.5 amps (minimum)
Operating Temperature
• 10º C (50º F) to 30º C (86º F)
Storage Temperature
• 0º C (32º F) to 40º C (104º F)
Relative Humidity
• 20% to 70% (non-condensing)
Calibration
One of the following:
• EAN/UPC Calibrated Conformance Test Card
• GS1-128 Calibrated Conformance Test Card
Specifications and photos subject to change.
