Data Structure Analysis Example
The above Figure is a screenshot of the Grading Tab verifying an EAN/UCC barcode label. The transmitted
encoded data is displayed in the upper right box. Clicking on the Structure Tab, the data is divided into its
data structural format.
Structure Tab showing the barcode data divided into its data structure format.
WARNING: The checking of Data Structure is complex and extensive. Microscan is
attempting to define all Data Structures but we may make an occasional error or may not
have a Data Structure defined that you require. If this is the case, please contact
Microscan and we will make the needed changes and/or additions in a future release of
the software. We thank you in advance for your help and cooperation.
